Fiber Optic Cable Ib hom Attenuator FC / APC:
FC Tib-hom Tsau Optical Attenuator feem ntau yog siv hauv kev ntsuas qhov muag. Nyob rau hauv thaum ntsuas optical receiver rhiab heev, feem ntau muab tso rau hauv lub optical receiver input los kho lub teeb lub teeb. Nws yog nyob rau hauv nruab nrab ntawm fiber ntau connector, haum rau txhua yam ntawm fiber optic connector nrog tag nrho cov kev ua tau zoo ntawm connectors. Thaum peb siv optical attenuator, thov ua kom ib puag ncig huv si thiab qhuav, muab lub kaus mom plua plav thaum tsis siv, tuav nrog kev saib xyuas, nruj me ntsis txwv kev sib tsoo.
|
Nta |
Daim ntawv thov |
|
Kev sib hloov tau zoo thiab rov ua dua |
Cov khoom siv kuaj |
|
Qhov tseeb attenuation tus nqi |
Kev sib txuas ntawm cov khoom siv |
|
Kev ntseeg siab |
Kev sib txuas ntawm jumper |
|
Muaj ntau yam xaiv tau |
Cable TV network |
|
Ua raws li IEC cov qauv thiab ROHS cov cai |
Metropolitan cheeb tsam network, dav cheeb tsam network |
Cov ntaub ntawv Specification:
|
Parameter |
Tus nqi |
Chav tsev |
|
Ua haujlwm Wavelength |
1310/1550 ± 10 |
nm |
|
Kev kam rau siab rau 1 ~ 5 dB Attenuation |
± 0.5 |
dB |
|
Kev kam rau siab rau 6 ~ 30 dB Attenuation |
± 10 |
dB |
|
Rov Los Los |
> 50 |
dB |
|
Ua haujlwm kub |
-40 rau +75 |
degree |
|
Polarization Dependent Poob |
Tsawg dua los yog sib npaug rau 0.1 |
dB |
|
Mating Durability |
Ntau tshaj los yog sib npaug rau 1000 |
Lub voj voog |
Cov nqe lus them nqi & Shipping:
|
Yam tsawg kawg nkaus Order Quantity |
100 nos |
|
Nqe |
Sib tham tau |
|
Ntim Cov Lus Qhia |
1 ea Nrog Anti-static Hnab |
|
Lub sij hawm xa tuaj |
3-5 hnub |
|
Cov nqe lus them nqi |
T / T lossis Western Union |
|
Muaj peev xwm muab khoom |
50, 000pcs txhua hli |
Puas yog Multimode lossis Single-mode Systems xav tau attenuators?
Feem ntau, multimode systems tsis xav tau attenuators. Multimode qhov chaw, txawm tias VCSELs, tsis tshua muaj hluav taws xob txaus rau cov neeg txais kev txaus siab. Ib hom kab ke, tshwj xeeb tshaj yog cov txuas luv, feem ntau muaj hwj chim ntau dhau thiab xav tau attenuators.
Technical Data:
|
Tsis muaj |
Zaus band |
Chav tsev |
|
Ua haujlwm wavelength |
1270-1610 |
nm |
|
Maximum Attenuation |
30 |
dB |
|
Qhov Kev Txhaum Txhaum Loj Tshaj Plaws |
Tsawg dua lossis sib npaug rau 0.5 |
dB |
|
Wavelength dependent Loss |
Tsawg dua lossis sib npaug rau 0.4 |
dB |
|
Optical rov poob |
Ntau dua lossis sib npaug li 45 |
dB |
|
Polarization dependent poob |
Tsawg dua los yog sib npaug rau 0.1 |
dB |
|
Kub nyob qhov poob |
Tsawg dua los yog sib npaug rau 0.1 |
dB |
|
Ua haujlwm kub |
-5 ~ +70 |
degree |
|
Cia Kub |
-40 ~ +85 |
degree |
|
Pob dimension |
27 (dia) X 18. {2}} (H) |
mm |
|
Yam khoom |
Specification |
|
Hom |
FC/APC Tsau Hom Attenuator Txiv neej rau poj niam |
|
Attenuation Range |
{0}} dB ± 0.5 dB |
|
Rov Los Los |
PC>50dB, UPC>55dB, APC>65dB ib |
|
Ua haujlwm Wavelength |
1310nm lossis 1550nm lossis 1310nm thiab 1550nm |
Rau Piv txwv Pob (Cov Khoom Zoo Anti-static Bag):
Package Description: Tsim kom haum ntim raws li cov duab ntawm cov khoom, peb muaj peev xwm muab zoo meej collocation ntawm cov khoom zoo thiab ilv ntim rau koj. Tiv tauj peb ntawmfocc@fiberfocc.comrau customizing koj pob attenuators.
Ordering Information:
1. FC/PC Ib hom Connector Hom Fiber Optic Attenuator
2. FC/APC Ib hom Connector Hom Fiber Optic Attenuator
3. FC/PC Multi-mode Connector Hom Fiber Optic Attenuator
4. FC/PC Ib hom Adapter Hom Fiber Optic Attenuator
5. FC/APC Ib hom Adapter Hom Fiber Optic Attenuator
6. FC/PC Multi-mode Adapter Hom Fiber Optic Attenuator
