Focc Foc Opic Refactive - coated teeb cables yog tsim los ua kom pom lub teeb ci los ntawm kev sib txuas rov qab los ntawm cov fiber ntau. Lawv tuaj yeem siv los tsim kev cuam tshuam fiber ntau lossis tsim kom muaj qhov qis- lub zog fiber ntau laser. Cov Retrorefectors yog qhov zoo tagnrho rau kev txiav txim siab rov qab xav txog cov kev qhia ntxiv rau transmitters, amplifters, thiab lwm yam khoom siv.

Ib hom, polarization {{0} tswj hwm, lossis cov retic retic retroreflector

● wavelengths los ntawm 450 nm rau 2400 nm

● FC / PC lossis FC / APC Txuas Versions muaj

product-453-453 product-481-480 product-390-390

Nta

Sm, tsaus ntuj, lossis hli Fiber Optic Retroreflector Thaj Cables

Ib tug kawg tau tiv thaiv cov nyiaj tsom iav

● R_avgNtau dua los yog sib npaug rau 97.5% los ntawm 450 nm mus rau fiber ntau lub suab sab sauv

2.0 mm nqaim tseem ceeb FC / PC lossis FC / APC version muaj

Tsim kom haum rau laser fais fab txog 300 mw

● 1 m ntev cables

retroreflector patch cables product-780-533

Peb cov Retroreflectors muaj nrog ib hom (sm), polarization {{0} tswj (mm), lossis multimode (hli) fiber ntau. Lub ferrule ntawm ib qho kawg ntawm cov fiber ntau yog coated nrog cov txheej muaj kev tiv thaiv los muab cov nyiaj nruab nrab ntawm ntau dua lossis sib npaug ntawm 450 nm mus rau lub teeb ci ntsa iab. Qhov kawg no yog encased nyob rau hauv ib tug ø9.8 mm (0.39 ") fiber ntau lub tsev uas tau sau nrog SM lossis PM sib txawv.

Ib hom Retroreflectors

Yam #	Lub paj Qho deb	MFD	Kev ntim Poob (ntaus.)	Cladding Qhov dav	Daim plhaub Qhov dav	Na	Tus txuas
P1-630R-P01-1	630 - 780 nm	3.6 - 5.3 µm @ 633 nm	4 DB	125 ±1.0 µm	245 ± 15 µm	0.10 - 0.14	FC / pc
P5-630R-P01-1	630 - 780 nm	3.6 - 5.3 µm @ 633 nm	4 DB	125 ±1.0 µm	245 ± 15 µm	0.10 - 0.14	Fc / APC
P1-780R-P01-1	780 - 970 nm	5.0 ± 0.5 µm @ 850 nm	3 DB	125 ± 1 µm	245 ± 15 µm	0.13	FC / pc
P5-780R-P01-1	780 - 970 nm	5.0 ± 0.5 µm @ 850 nm	3 DB	125 ± 1 µm	245 ± 15 µm	0.13	Fc / APC
P1-1060R-P01-1	980 - 1550 nm	5.3 - 6.4 µm @ 980 nm	2 dB	125 ± 1 µm	245 ± 15 µm	0.13 - 0.15	FC / pc
P5-1060R-P01-1	980 - 1550 nm	5.3 - 6.4 µm @ 980 nm	2 dB	125 ± 1 µm	245 ± 15 µm	0.13 - 0.15	Fc / APC
P1 {- smf28er-p01-1	1260 - 1625 nm	9.2 ± 0.4 µm @ 1310 nm 10.4 ± 0.5 µm @ 1550 nm	0.6 db	125 ± 0.7 µm	242 ± 5 µm	0.14	FC / pc
P5 {- smf28er-p01-1	1260 - 1625 nm	9.2 ± 0.4 µm @ 1310 nm 10.4 ± 0.5 µm @ 1550 nm	0.6 db	125 ± 0.7 µm	242 ± 5 µm	0.14	Fc / APC

Polarization {{0} Taug Kev Tswj Xyuas Retrorefors

Yam #^a	Lub paj Qho deb	MFD^b	Kev ntim Poob (max)^c	Tu noob Feem (min)	Cladding Qhov dav	Daim plhaub Qhov dav	Na	Tus txuas^d
P1 {- 630pmr-p01-1	620 - 850 nm	4.5 ± 0.5 µm @ 630 nm	2.4 dB	18 DB	125 ± 2 µm	245 ± 15 µm	0.12	FC / pc
P5 {- 630pmr-p01-1	620 - 850 nm	4.5 ± 0.5 µm @ 630 nm	2.4 dB	18 DB	125 ± 2 µm	245 ± 15 µm	0.12	Fc / APC
P1 {- 780pmr-p01-1	770 - 1100 nm	5.3 ± 1.0 µm @ 850 nm	2.0 db	18 DB	125 ± 2 µm	245 ± 15 µm	0.12	FC / pc
P5 {- 780pmr-p01-1	770 - 1100 nm	5.3 ± 1.0 µm @ 850 nm	2.0 db	18 DB	125 ± 2 µm	245 ± 15 µm	0.12	Fc / APC
P1 {- 1060pmr-p01-1	970 - 1550 nm	6.6 ± 0.5 µm @ 980 nm	1.4 dB	22 dB	125 ± 1 µm	245 ± 15 µm	0.12	FC / pc
P5 {- 1060pmr-p01-1	970 - 1550 nm	6.6 ± 0.5 µm @ 980 nm	1.4 dB	22 dB	125 ± 1 µm	245 ± 15 µm	0.12	Fc / APC
P1 {- 1550pmr-p01-1	1440 - 1625 nm	10.1 ± 0.4 µm @ 1550 nm	1.0 dB	22 dB	125 ± 2 µm	245 ± 15 µm	0.12	FC / pc
P5 -} 1550pmr-p01-1	1440 - 1625 nm	10.1 ± 0.4 µm @ 1550 nm	1.0 dB	22 dB	125 ± 2 µm	245 ± 15 µm	0.12	Fc / APC
