● Khoom Qhia:
13101490 / 1550nm FWDM muaj peev xwm paub txog cov kev sib txuam thiab kev sib tw ntawm ob txoj kev sib txuas lus 1490/1310 thiab 1550. Nws yuav ua kom muaj peev xwm ntawm ib tus fiber ntau los ua kom tiav kev sib txuas lus, yog li ntawd siv ntau qhov kev hloov kho lub network thiab nthuav tawm, lossis qhia txog kev lag luam tshiab thiab lwm yam. Lim hom WDM yog raws li kev pov thawj yeeb yaj kiab lim hlau. Qhov WDM no yog siv rau cov kev sib txuas lus fiber ntau ntawm fiber ntau thiab EDFA qhov chaw uas yuav tsum muaj kev sib tw thiab sab nrauv.
● Nta:
► Cov qhab ntse ntse sab nrauv;
► Tshem tawm txoj hauv siab siab;
► Kev ruaj siab thiab kev cia siab.
● Cov ntawv thov:
► EDFA;
► WDM systems;
► CATV.
● Kev Ua Tau Zoo:
| Parameter | Txheem | |
Dhau ntawm Channel wavelength Ntau (nm) | 1550 ± 10 | |
Reflect Channel wavelength (nm) | 1310 ± 40 & 1490 ± 10 | |
Insertion poob (dB) | Tshaj Channel | <> |
Xav txog channel | <> | |
Insertion poob Plug (dB) | Tshaj Channel | ≤0.30 |
Xav txog Channel | ≤0.30 | |
Kev rho tawm (dB) | Tshaj Channel | ≥40 |
Xav txog Channel | ≥20 | |
Tso Tsis Taub Txawv Kev Kub Siab (dB / ℃) | <> | |
Polarization Dispersion loss (dB) | ≤0.10 | |
Polarization hom Dispersion (ps) | <> | |
Ncaj Ncees (dB) | ≥ 55 | |
Rov Qab Los (dB) | ≥ 50 | |
Max hwjchim ua haujlwm (mw) | 300 | |
Fiber hom | SMF-28e | |
Cov ntaub ntawv cov khoom yog yuav hloov tsis tau daim ntawv ceeb toom | ||
● Hais Qhia:
FWDM | |
XXX | Chaw nres nkoj: 1X2 thiab lwm yam. |
TXXXX | Kev kis tus kab mob wavelength |
RXXXX | Thiaj tshav puam |
X | Pigtail hom: 0 = 250μm, 1 = 900μm, 2 = 2mm, 3 = 3mm, 4 = lwm tus |
X | Fiber Code: 000 = SMF-28e, 001 = HI1060, 002 = 50/125, 003 = 62.5 / 125, 999 = lwm tus |
XXX | Connector: FC / APC, SC / APC thiab lwm yam |
XX | Lub hnab me: 5.5 × 34, 5.5 × 35 thiab lwm yam. |
● Ntau Yam Khoom Sib FTTX:
Txais tos kom tus fttx dhau 1310nm bandwidth qhia txog 1550nm fiber ntau optical fwdm lim wdm splitter nrog peb lub Hoobkas. Ua ib lub tuam txhab ua lag luam thiab cov muag khoom nyob rau hauv Suav teb, peb kuj txais tos kev txiav txim siab. Ntsib tus nqi thiab cov lus nrog peb tam sim no.
