Txais tos muas 10gbase-bx40-u smf 1270nm-tx / 1330nm-rx 40km ib ntus ntawm cov ntaub ntawv + transceiver module cisco sfp-10g-bx40u-kuv tau tshaj peb lub Hoobkas. Ua ib lub tuam txhab ua lag luam thiab cov muag khoom nyob rau hauv Suav teb, peb kuj txais tos kev txiav txim siab. Ntsib tus nqi thiab cov lus nrog peb tam sim no.

● Qhia Txog:
Kub ntsaws cov kab mob SFP + hneev taw Kev txhawb zog 9.95 rau 10.3 Gb / s Bitrates Fais fab tuag dissipation <1w rohs-6="" raws="" li="" cov="" tsis="" muaj="" teeb="" meem="" (cov="" hlau="" lead="" tsis="" muaj)="" commercial="" temperature="" ranges="" 0="" ℃="" to="" 70="" ℃="" ib="" qho="" 3.3vpower="" hwj="" xwm="" ntau="" qhov="" txuas="" ntev="" ntawm="" 300m="" ntawm="" 2000="" mhz-km="" mmf="" receiver="" limiting="" hluav="" taws="" xob="" interface="" duplex="" lc="" connector="" built-in="" digital="" diagnostic="" functions="" 850nm="" vcsel="" transmitter,="" pin="" photo-detector="" all-metal="" tsev="" rau="" superior="" emi="" kev="" kawm="" advanced="" firmware="" cia="" neeg="" qhauj="" encryption="" cov="" ntaub="" ntawv="" yuav="" tsum="" tau="" muab="" hauv="">

● Khoom nta:
► Kev khiav hauj lwm cov ntaub ntawv nce mus txog 10.3Gbps;
► 1270 los yog 1330nm BOSA rau 20/40 / 60km;
► 1490 lossis 1570nm BOSA rau 80km;
► 20 km los yog 40 km los yog 60 km los yog 80 km tshaj ib zaug ntawm ib leeg;
► Ib qho 3.3V zog mov thiab TTL logic interface simplex LC connector interface.

● Daim Ntawv Thov:
► Fiber Channel Links;
► WDM Gigabit Ethernet Links;
► Fiber Channel.

● Siv tau zoo dua:
► Muaj kev ntseeg siab thiab sib luag;
► Nqe zoo;
► Txuj kev sib tw (CISCO / HP / Extreme / Juniper);
► OEM / ODM Cov ntawv sau ua qauv;
► Kev xa zais.

image003 (001) .jpg

● Cov yam ntxwv ntawm tus cwj pwm zoo:

Cov lus qhia	Cim	Min	Hom	Max	Chav tsev
20km
Center Wavelength BXD	λC	1320	1330	1340	nm
Center Wavelength BXU	λC	1260	1270	1280	nm
Spectral dav (RMS)	σ			1	nm
Nruab Nrab Sab Zog	P0ut	-3		+2	dBm
Ntxiv Kev Tshaj Tawm	Nc	3.5	6		dB
40km
Center Wavelength BXD	λC	1320	1330	1340	nm
Center Wavelength BXU	λC	1260	1270	1280	nm
Spectral dav (RMS)	σ			1	nm
Nruab Nrab Sab Zog	P0ut	0		5	dBm
Ntxiv Kev Tshaj Tawm	Nc	3.5	6		dB
60km
Center Wavelength BXD	λC	1320	1330	1340	nm
Center Wavelength BXU	λC	1260	1270	1280	nm
Spectral dav (RMS)	σ			1	nm
Nruab Nrab Sab Zog	P0ut	1		5	dBm
Ntxiv Kev Tshaj Tawm	Nc	3.5	6		dB
80km
Center Wavelength BXD	λC	1530	1570	1580	nm
Center Wavelength BXU	λC	1480	1490	1500	nm
Spectral dav (RMS)	σ			0.3	nm
Nruab Nrab Sab Zog	P0ut	1		5	dBm
Ntxiv Kev Tshaj Tawm	Nc	8.2			dB
Output Optical Eye	Ua raws li FC_FI_4 REV 7.0
Cov ntaub ntawv tawm tswv yim viav vias txawv	VIN	180		700	mV
Tswv yim Differential Impedance	ZIN	85	100	115	Ω
TX Txhaum Tawm High	TxFh	2.4		Vcc	V
TX Txhaum Tawm Tsawg	TxFl	-0.3		0.8	V
TX Txaus Siab Tawm Tawm	TxDh	2		Vcc + 0.3	V
TX Txaus Siab Txo Tsawg	TxDl	-0.3		0.8	V

● Txais qhov muag pom kev:

Cov lus qhia	Cim	Min	Hom	Max	Chav tsev
20km
Center Wavelength BXD	λC	1260	1270	1280	nm
Center Wavelength BXU	λC	1320	1330	1340	nm
Reveiver Sensitivity	Koj	-14.5			dBm
Cov tswv yim siab tshaj	Pmax	0			dBm
LOS De Assert	LOSS			-14	dBm
LOS POM ZOO	LOSA	-25			dBm
Tsis muaj Hysteresis	LOSH	0.5		4	dBm
40km
Center Wavelength BXD	λC	1260	1270	1280	nm
Center Wavelength BXU	λC	1320	1330	1340	nm
Reveiver Sensitivity	Koj	-16			dBm
Cov tswv yim siab tshaj	Pmax	0			dBm
LOS De Assert	LOSS			-17	dBm
LOS POM ZOO	LOSA	-27			dBm
Tsis muaj Hysteresis	LOSH	0.5		4	dBm
60km
Center Wavelength BXD	λC	1260	1270	1280	nm
Center Wavelength BXU	λC	1320	1330	1340	nm
Reveiver Sensitivity	Koj	-22			dBm
Cov tswv yim siab tshaj	Pmax	-7			dBm
LOS De Assert	LOSS			-23	dBm
LOS POM ZOO	LOSA	-33			dBm
Tsis muaj Hysteresis	LOSH	0.5		4	dBm
80km
Center Wavelength BXD	λC	1480	1490	1500	nm
Center Wavelength BXU	λC	1530	1570	1580	nm
Reveiver Sensitivity	Koj	-22		-7	dBm
Cov tswv yim siab tshaj	Pmax	-7			dBm
LOS De Assert	LOSS			-24	dBm
LOS POM ZOO	LOSA	-34			dBm
Tsis muaj Hysteresis	LOSH	0.5			dBm
Dispersion nplua				3.0	dBm

● Cov khoom hluav taws xob:

Cov lus qhia	Cim	Min	Hom	Max	Chav tsev	Cov lus qhia
Muab Voltage	Vcc	3.14	3.3	3.46	V
Khoom Tam Sim No 20km	Icc		270	350	mA
Khoom Tam Sim No 40km			300	450	mA
Khoom Tam Sim No 60km			300	450	mA
Khoom Tam Sim No 80km				500	mA

Muab Voltage	Vcc	3.14	3.3	3.46	V
Muab Tam Sim No	Icc			300	mA
Siv Cov Lus Qhia Txawv Impedance	Zd		100		mA
Input AC Hom Tawm Tswv Yim Voltage		0	25		mA
Txawv Ntawm Tswv Yim Cov Peev Xwm Vias	VID	150		900	mA
Tag nrho Jitter
Cov Ntaub Ntawv Txaus Siab Tshaj
Uncorrelated Jitter
Qhov muag pob ntseg	Saib SFP + MSA	X1				UI
Qhov muag pob ntseg	Saib SFP + MSA	X 2			0.35	UI

● DOM tsis:

Cov lus qhia	Min	Max	Chav tsev
Transponder kub saib qhov tseeb	-5	+5	℃
Laser bias tam sim no saib xyuas qhov tseeb	-10	+10	%
Xa hwj chim saib xyuas cov lus	-2	+2	dB
Tau txais lub hwj chim saib xyuas cov lus	-2	+2	dB

● Tej yam tsis zoo:

Cov lus qhia	Cim	Min	Max	Chav tsev
Cia txias	Ts	-40	85	℃
Fais fab tuag voltage	Vcc	-0.5	4	V
Qhov teeb meem ntawm qhov input voltage		-0.3	Vcc + 0.3	V
Kev khiav haujlwm temp COM version		0 ℃	70 ℃
Kev ua hauj lwm sij hawm IND		-40 ℃	+ 85 ℃

Peb muaj ntau Fiber Optic Transceiver uas koj xav tau thiab thov tos txais koj tus RFQ peb sim peb cov kev pab zoo tshaj plaws rau koj txhua tus. Ua tsaug.

Cim npe nrov: 10gbase-bx40-u smf 1270nm-tx / 1330nm-rx 40km hauv lub lc bd bidi sfp + transceiver module cisco sfp-10g-bx40u-kuv tshaj, Tuam Tshoj, chaw lag luam, lwm tus neeg, manufacturers, quotes, customized, nqe, yuav

10GBASE-BX40-U SMF 1270nm-TX / 1330nm-RX 40km DOM LC WDM BiDi SFP + Transceiver Module Cisco SFP-10G-BX40U-Kuv Tshaj
