● Qhia Txog:
Qhov Plaub Me (Quad Small Form-Pluggable Pluggable Pluggable) (QSFP los yog QSFP +) yog ib qho kev sib cog lus, muaj ntaub ntawv sib txig rau cov ntaub ntawv sib txuas lus. Nws interfaces ib qhov cuab yeej ntaus network (rau qhov hloov, router, media converter lossis lwm yam cuab yeej) rau ib qho fiber optic cable. Nws yog ib hom kev lag luam uas tau tsim los tsim thiab txhawb los ntawm ntau tus neeg muag khoom network. QSFP + hloov cov ntaub ntawv yog tsim los txhawb Serial Attached SCSI, 40G Ethernet, 20G / 40G Infiniband, thiab lwm cov qauv kev sib txuas lus. QSFP Transceiver muaj 40GBASE-SR4 thiab 40GBASE-LR4 rau cov ntawv sib txawv. Cov AscentOptics 40GBASE QSFP + (Quad Small Form-Factor Pluggable Plus) Cov kev pabcuam muaj cov qhua tuaj yeem muaj ntau cov kev sib txuas ntawm 40 Gigabit Ethernet connectivity options rau cov ntaub ntawv chaw, cov chaw ua haujlwm qiv, cov tub ntxhais lag luam thiab kev faib tawm, thiab cov kev pabcuam thauj cov ntaub ntawv.
● Direct kev txuas rau Cisco 40G QSFP + SR4 / CSR4 Transceiver:
Yam khoom | ID # | Kev piav qhia |
① | 36157 | Cisco QSFP-40G-SR4 Tshaj QSFP + 850nm 150m MTP / MPO |
② | 39700 | One-Click Cleaner rau MTP / MPO Connector (600 cleans) |
③ | 43934 | 1m (3ft) MTP-12F Poj niam OM4 50/125 Lub cev pob hlau, Polarity B, Cov neeg tseem ceeb, LSZH Rev |
④ | 43514 | 96 fibers 12x MTP-8 rau LC / UPC OM4 1U Breakout Thaj Vaj Huam Sib Luag Ca, MTP Txiv neej Elite IL 0.35dB, Polarity A |
⑤ | 34873 | One-Click Cleaner rau LC / MU 1.25mm Ferrules (800 cleanses) |
⑥ | 40180 | 1m (3ft) LC UPC mus rau LC UPC Duplex 2.0mm PVC (OFNR) 10G OM4 Fibre Patch Cable |
⑦ | 11589 | Generic Compatible 10GBASE-SR SFP + 850nm 300m LC DOM |
⑧ | 29123 | S5850-48S6Q (48 * 10GE + 6 * 40GE) Kev Tshaj Tawm Cov Ntaub Ntawv Siab |
● Daim Ntawv Thov:
● Nqe lus piav qhia:
| Cisco Genuine | QSFP-40G-IR4 |
Daim Ntawv Hom | QSFP + |
Cov Ntaus Ntawv Tau Tshaj Tawm | 41.25Gbps |
Wavelength | 1310nm |
Max Cable nrug | 10km |
Interface | MTP / MPO |
Optical Cheebtsam | SMF |
Cable Hom | Nrog DOM |
DOM Kev Pabcuam | Muaj |
TX fais fab | -5.6 ~ 3dBm |
Txais Kev Mob Siab | <> |
HTS-Harmonized Code | 8517706000 |
● Cov yam ntxwv ntawm tus cwj pwm zoo:
Parameter | Cim | Min | Hom | Max | Chav tsev | |
Lub Hwj Laum Siab Tshaj Plaws | PMAX | -3 | +0.5 | dBm | ||
Optical Center Wavelength | UBXFP-20-U | λ | 1260 | 1270 | 1280 | nm |
UBXFP-20-D | 1320 | 1330 | 1340 | |||
Optical Extinction Ratio | ER | 3.5 | dB | |||
Spectral dav | Δλ | 1 | nm | |||
Sidemode kev yuam piv | SSRmin | 30 | dB | |||
Sij Hawm / Sij Hawm Sij Hawm (20% ~ 80%) | Tr / Tf | 50 | ps | |||
Qhov muag pob qhov muag muag | IEEE802.3ae | |||||
Kev Siv Hnub Txiav Hnub | BR | 9.95 | 11.3 | Gb / s | ||
Txais Kev Mob Siab | Koj | -14.5 | dBm | |||
Cov Pawm Tsawg Siab Tshaj | PMAX | 0 | dBm | |||
Optical Center Wavelength | UBXFP-20-U | λC | 1320 | 1330 | 1340 | nm |
UBXFP-20-D | 1260 | 1270 | 1280 | |||
Tau Txais Kev Ntseeg | Rrx | -14 | dB | |||
LOS De Assert | LOSD | -15 | dBm | |||
LOS POM ZOO | LOSA | -30 | dBm | |||
Tsis muaj Hysteresis | LOSH | 0.5 | 5 | dB | ||
● Daim Ntawv Tso Cai Zoo Tshaj Plaws:
Kev zoo thiab cov qauv yog lub hauv paus ntawm FOCC. Peb tau mob siab los muab cov qhua tuaj noj mov nrog cov khoom zoo, cov khoom siv thiab cov kev pab cuam. FOCC tau siv ntau qhov kev soj ntsuam zoo, xws li lub CE, RoHS, FCC, tsim ib qho kev txhim kho zoo thoob ntiaj teb thiab tswj hwm kev tswj thiab tswj hauv kev tsim, kev tsim, kev tsim, kev teeb tsa thiab kev pabcuam. Thov Nco Ntsoov: Txhim kho ib tus neeg sab nrauv hloov tsis tau koj cov khoom siv hluav taws xob network. Txhua tus neeg siv khoom siv hluav taws xob muaj cov txheej txheem qhia tias kev them nyiaj yug rau lawv cov khoom yuav tsis raug cuam tshuam.
● Lub neej Warranty:
Tag nrho cov khoom siv fiber ntau hauv FOCC muaj kev lees paub tiv thaiv cov khoom siv thiab cov khoom ua haujlwm nrog rau lub neej. Qhov kev tiv thaiv no tsis them rau kev puas tsuaj los ntawm kev sib tsoo, kev saib xyuas tsis zoo, kev siv tsis zoo, kev tsis saib xyuas, kev hnav thiab tu dua, los yog kev sib cais ntawm cov xim thiab cov ntaub ntawv dhau sijhawm thiab siv.
Qee 10Gbps XFP transceivers yog raws li XFP Cov Ntawv Pom Zoo Tshaj Xo (MSA). Lawv ua raws li 10-Gigabit Ethernet 10GBASE-LR / LW ntawm IEEE 802.3ae, SONET OC-192 / SDH thiab 10G Fiber Channel 1200-SM-LL-L. Kev tshawb nrhiav cov kab mob muaj nyob rau ntawm 2-wire serial interface, raws li teev nyob rau hauv XFP MSA.
