Yog tias koj tau siv txhua lub sijhawm nkag mus nyob ib puag ncig cov ntaub ntawv niaj hnub lossis sim xyuas seb vim li cas koj tus txiv neej network pheej tham txog 'siab-cov kev daws teeb meem fiber ntau,' tej zaum koj tau hnov cov lusMPOpov ib ncig. Tej zaum MTP ib yam nkaus. Tib neeg siv lawv sib pauv hloov tau - uas yog technically zoo, txij li MTP tsuas yog US Conec lub npe zoo nkauj ntawm MPO tus qauv. Tab sis qhov ntawd tsis yog qhov tseem ceeb ntawm no.
Qhov teeb meem yog qhov twg cov khoom no tau siv tiag tiag. Thiab ncaj ncees? Cov lus teb yog: ntau qhov chaw tshaj qhov koj xav.
Data Centers (Ntawm qhov tseeb)
Qhov no yog ib hom gimme. Cov chaw zov me nyuam yog qhov chaw MPO cables tiag tiag pom lawv lub tsev, thiab yog vim li cas. Thaum koj tab tom cuam tshuam nrog 40G, 100G, lossis tam sim no txawm tias 400G thiab 800G kev sib txuas, cov qub duplex LC cables cia li tsis txiav nws ntxiv lawm. Xav txog nws: 100G-SR4 transceiver xav tau 8 fibers-4 kis, 4 tau txais. Koj tuaj yeem khiav plaub txoj kab hluav taws xob sib cais, lossis koj tuaj yeem siv ib lub cev MPO-12 thiab hu nws ib hnub.
Qhov kev sib cav ntom ntom kuj tseem ceeb heev. Ib leeg MPO-12 connector packs 12 fibers rau hauv kwv yees tib yam hneev taw raws li tus qauv LC connector. Qee qhov kev ua lej nrawm: 1U thaj vaj huam sib luag uas tuaj yeem tuav 24 LC chaw nres nkoj tuaj yeem ua kom haum 72 fibers tsim nyog ntawm MPO kev sib txuas. Thaum qhov chaw khib nqi nws ua li cas -tshwj xeeb tshaj yog nyob rau hauv hyperscale chaw-uas tsis yog tsis muaj dab tsi.
Cov qauv xa tawm raug mus rau qee yam zoo li no: MPO lub cev cables khiav ntawm racks lossis chaw faib khoom, ces tawg mus rau LC cassettes ze ntawm cov servers. Nws yog ib tug modular mus kom ze. Koj puas xav hloov kho los ntawm 10G mus rau 100G? Hloov cov cassettes, khaws lub nraub qaum. Cov tub ntxhais hluas infrastructure nyiam qhov no.
Telecom thiab 5G Networks
Ntawm no yog qhov uas nws tau txais kev txaus siab. 5G xa tawm tau tsim qhov kev thov loj heev rau siab - fiber ntau sib txuas, tshwj xeeb tshaj yog nyob rau hauv pem hauv ntej thiab backhaul daim ntawv thov. Kev sib txuas xov tooj cua mus rau kev ua haujlwm hauv baseband yuav tsum muaj bandwidth loj, thiab lub sijhawm teeb tsa kev teeb tsa yog khaus. Tsis muaj leej twg xav tau cov kws tshaj lij sib txuas cov fibers hauv thaj teb thaum lawv tuaj yeem ntsaws rau hauv ua ntej - txiav MPO cov rooj sib tham.
Tus neeg teb xov tooj hauv Kaus Lim Qab Teb -ib tus neeg siv 5G thaum ntxov- tau tshaj tawm tias txiav lub sijhawm xa mus los ntawm 40% hloov mus rau MPO-16 rau lawv 200G fronthaul txuas. Qhov ntawd yog hom lej uas ua rau CFOs saib xyuas.
Enterprise thiab Campus Networks
Cov tsev kawm ntawv, cov tsev kawm ntawv loj, cov tsev kho mob. Zoo nkauj heev nyob qhov twg koj tau txais ntau lub tsev uas yuav tsum tau tham nrog ib leeg ntawm kev kub ceev. Cov pob txha khiav feem ntau yog MPO lub cev, tawg mus rau txhua yam khoom siv kawg xav tau. Tsis muaj ntau los hais ntawm no-nws yog tib qhov ceev-thiab- zaj dab neeg ceev, tsuas yog ntsuas qhov sib txawv.
Tshaj tawm thiab tshaj lij AV
Qhov no surprises neeg. Cov chaw tshaj tawm xov xwm muaj qee qhov xav tau tshaj plaws kev xa xov video nyob ib puag ncig - tsis muaj kev sib txuas 4K thiab 8K cov cim yuav tsum muaj bandwidth loj heev. Ib txwm tooj liab tsuas yog tsis tuaj yeem lis nws dhau qhov kev ncua deb. Tab sis ntawm no yog qhov khoom: tshaj tawm cov engineers kuj nyiam ua kev saib xyuas. Lawv tsis tau txais cov thev naus laus zis tshiab tshwj tsis yog lawv ntseeg siab tias nws yuav tsis poob thaum lub sijhawm tshaj tawm.
MPO tau ua inroads vim nws daws teeb meem tiag tiag. Studio tswj cov chav nyob yog cramped. Cov kab hauv kab tau ntim. Kev khiav siab - fiber ntau txhais tau tias koj tuaj yeem tau txais cov teeb liab ntau dua los ntawm qhov chaw nruj dua. Ntxiv rau, qhov ua ntej- txiav tawm qhov xwm txheej txo ntawm - qhov chaw teeb tsa yuam kev- uas tseem ceeb heev thaum koj txuas chav tswj ntawm 2 teev sawv ntxov ua ntej sawv ntxov.
Ntau cov tsheb thauj khoom siv lawv thiab. Cov tsheb loj tshaj tawm hauv xov tooj cua uas koj pom ntawm kev sib tw ncaws pob? Qhov chaw txwv, kev ntseeg siab heev. MPO haum rau daim nqi.
Cov Tsev Kho Mob
Cov chav ua haujlwm streaming kev phais video rau kev cob qhia. MRI thiab CT scanners thawb cov duab loj heev rau cov chaw ua haujlwm kuaj mob. Txhua qhov chaw kho mob ua tau raws li cov txheej txheem hauv network, feem ntau koj yuav pom MPO cabling ua qhov nqa hnyav. Kev tiv thaiv EMI ntawm fiber ntau yog qhov tseem ceeb ntawm no - tsis muaj kev cuam tshuam los ntawm txhua yam khoom siv ntawd.
Yog li Vim Li Cas Qhov no Tseem Ceeb?
Ua siab ncaj, yog tias koj nyeem qhov no, tej zaum koj twb tau cuam tshuam nrog MPO cables nyob rau hauv koj ib puag ncig -los yog koj tab tom yuav. Cov thev naus laus zis tau dhau los ntawm 'tus qauv tshiab' theem. Nws tsuas yog yuav ua li cas tam sim no ua tiav rau txhua yam saum toj no 10G hauv feem ntau kev xa khoom lag luam.
Cov chaw xa khoom mus txuas ntxiv. Kuv tau hnov txog MPO siv hauv:
Siab -frequency trading floors (latency obsession)
Cov tsev kawm ntawv tshawb fawb nrog suav nrog pawg
Smart City infrastructure tej yaam num
Txawm hais tias qee qhov siab -qhov kawg hauv tsev nyob, txawm tias qhov ntawd tseem tsawg heev
Cov qauv zoo ib yam: txhua qhov chaw koj xav tau fiber ntau, xa tawm sai, thiab qhov chaw tsawg, MPO tshwm sim.
Daim ntawv ceeb toom ceev
Kev suav fiber ntau txawv los ntawm daim ntawv thov. 8- fiber ntau cables rau feem ntau 40G / 100G parallel optics. 12- fiber ntau yog tseem muaj vim tias qhov ntawd yog qhov kev xa tawm thaum ntxov siv . 16- fiber ntau tau txais traction rau 400G ua haujlwm . 24- fiber ntau rau 100G configurations (xws li 100G ASE10) . Koj tuaj yeem tau txais lawv txhua txoj kev mus txog 72 lossis 144 fibers hauv kev teeb tsa lub cev.
Polarity tseem ceeb heev, tab sis qhov ntawd yog ib qho kev sib tham tag nrho. Cia peb hais tias: yog tias koj tab tom qhia MPO cable khiav, xyuas kom ib tus neeg nkag siab hom A / B / C polarity koom nrog hauv kev tsim. Ua tsis ncaj ncees txhais tau tias cov teeb liab mus tsis pom qhov twg.
Kab hauv qab
MPO cables tsis nyob txhua qhov chaw. Cov chaw ua haujlwm me me, kev teeb tsa hauv tsev, txhua yam hauv qab 10G-tej zaum tsis tsim nyog rau qhov nyuaj. Tab sis qhov chaw pib tseem poob qis. Dab tsi yuav tsum tau 100G kev sib txuas tsib xyoos dhau los tam sim no xav tau 400G. Cov ntawv thov uas xav tau 400G yog qhov muag 800G thiab tshaj.
Yog tias koj tab tom tsim kev tsim kho vaj tse uas yuav tsum tau siv sijhawm ntev dua li ob peb xyoos, nkag siab qhov twg MPO haum rau - thiab qhov twg nws mus rau qhov twg - tsis xaiv ntxiv lawm. Nws tsuas yog ib feem ntawm txoj haujlwm.
Data centers, telecom, enterprise, tshaj tawm, kho mob. Qhov ntawd yog daim ntawv qhia tam sim no. Tab sis cov tes hauj lwm tsis nres evolving, thiab tsis ua cov cables txuas rau lawv.
