PLC Fiber Splitter, Mini Module, 900μm, SC / APC
1x16 Blockless Fiber PLC Splitter, Singlemode,
900μm Fiber, SC / APC Connector
PLC splitters yog siv los cais lossis sib txuas cov teeb liab kho qhov muag. PLC (planar lightwave circuit) yog micro-optical tivthaiv raws li cov qauv siv hluav taws xob hluav taws xob hluav taws xob thiab muab cov khoom siv hluav taws xob qis qis nrog cov qauv me me thiab kev ntseeg siab. PLCs yog tsim los siv silica iav waveguide circuits uas ua raws li cov v-groove fiber array nti uas siv ribbon fiber ntau. Thaum txhua yam sib dhos thiab sib koom ua ke, nws yog tom qab ntawd ntim rau hauv lub tsev me me. PLC splitters muaj kev ua tau zoo, xws li tsis tshua muaj qhov poob, PDL qis, siab rov qab poob, thiab lwm yam.
Khoom Paub meej
|
Pob Style |
Mini Module |
Hom kev teeb tsa |
1x16 |
|
Hom Fiber |
Singlemode G.657A1 |
Hom Connector |
SC/APC |
|
Fiber Diameter |
900μm |
Fiber Length |
>1m |
|
Insertion Loss |
Tsawg dua lossis sib npaug li 13.8dB |
Rov Los Los |
Ntau dua lossis sib npaug li 50dB |
|
Loss Uniformity |
Tsawg dua lossis sib npaug rau 1.0dB |
Kev taw qhia |
Ntau dua lossis sib npaug li 55dB |
|
Polarization Dependent Poob |
Tsawg dua lossis sib npaug rau 0.3dB |
Temperature Dependent Loss |
Tsawg dua los yog sib npaug rau 0.8dB |
|
Wavelength Dependent Poob |
Tsawg dua los yog sib npaug rau 0.5dB |
Ua haujlwm Bandwidth |
1260-1650 nm |
|
Ua haujlwm kub |
-40 ~ 85 degree |
Cia Kub |
-40 ~ 85 degree |
Khoom Taw Qhia
Blockless PLC Splitter
v 1x16 Spliting, SC / APC Connector
Kev poob qis qis, qis polarization nyob ntawm qhov poob, qis rov qab xav txog, thiab zoo uniformity.
v Chips zoo heev
Kev poob ntawm lub teeb tsis yog rhiab rau wavelength, thiab nws tuaj yeem ua tau raws li qhov kev xav tau ntawm kev sib txawv wavelengths.
v Compact Structure
Me me, nws tuaj yeem ntsia ncaj qha rau hauv ntau lub thawv hloov pauv thiab tsuas yog siv qhov chaw me me xwb.
v Exquisite Ntim
Kev tsim thiab ntim khoom yog qhov zoo heev los xyuas kom meej cov khoom zoo.
v Zoo tagnrho rau EPON, GPON, FTTH / FTTX network
Cov ntsiab lus zoo meej ntawm 1X16 Blockless PLC Splitter
Kev sib txuas yooj yim thiab yooj yim
Blockless PLC splitter tuaj yeem ntsia tau yooj yim hauv fiber ntau splice kaw, optical faib lub thawv rau qhov chaw txuag thiab tsis tas yuav tsum tau splice.lawv muaj kev ua haujlwm ntawm txhua yam splice, fusion splice, lub teeb splitting, xaim xaim, thiab lwm yam. Tsis tas li ntawd, qhov ntau ntawm pigtail thiab adapters uas tau thauj khoom hauv lub thawv txiav tawm no kuj tuaj yeem sib phim yooj yim.
PLC optical splitter Cheebtsam
PLC optical splitter yog ib qho tseem ceeb tshaj plaws ntawm cov khoom siv hluav taws xob nyob rau hauv ib qho kev sib txuas ntawm fiber ntau optical, thiab yog ib qho khoom siv kho qhov muag fiber ntau uas muaj ntau qhov kawg thiab ntau qhov tso tawm.
Ntawm lawv, nws peb yam tseem ceeb tshaj plaws yog cov tswv yim, cov zis, thiab nti ntawm fiber ntau array.
Kev tsim thiab kev sib dhos ntawm peb cov khoom no ua lub luag haujlwm tseem ceeb hauv seb PLC optical splitter tuaj yeem ua haujlwm ruaj khov thiab ib txwm.
1, ribbon fiber 2, fiber ntau array V-groove
3, Externalfiber ntauarray4, interface splitter nti / fiber ntau array
5, epoxy resin 6, input fiber ntau array
7, fiber ntau array npog 8, splitter nti
9, kawg cap tiv thaiv npog10, cev
Mechanical Drawing:
Liab qab fiber ntau PLC Splitter (nrog ribbon fiber ntau outputs)
Micro Tube PLC Splitter (nrog 900um fiber ntau outputs)
Cov ntaub ntawv ntim khoom
B.Standalone thawv thawv
C.Economical packing -- Ib lub thawv ntawv muaj ob peb yam khoom
A B C
a.1x2, 1x4, 1x8, 1x16,1x32, 1x64, 2x2, 2x4, 2x8, 2x16, 2x32,2x64 Versions of splitters are available.
b. SC / UPC, FC / UPC, LC / UPC, SC / APC, FC / APC, LC / APC connectors los yog tsis muaj connectors yuav xaiv tau raws li koj nyiam
c. Qhov ntev ntawm pigtail tuaj yeem hloov kho; feem ntau peb yuav muab rau koj 1.5m.
