● Qhia Txog:
FOCC's Small Form Factor Pluggable (SFP) kev xa ntawv tau zoo tshaj qhov ntsuas tau txhais los ntawm SFP Multi-Sourcing Agreement (MSA). Tus FOCC Cisco tshaj qhov tsim muaj cov ntawv me me uas muaj fiber ntau ntau yog siv ua ob tog. Cov kev sib tshuam no xa tawm thiab tau txais kev tshaj tawm ntawm ib qho hlua khoob siv ob lub piam. Cov pob zeb zoo tshaj plaws hauv lub cav sib tawb no muaj ob ntu: qhov kev sib txuas lus siv 1490 nm DFB laser / 1550 nm Fabry-Perot laser; cov tshooj ntawv siv lub hom B daim ntawv A / A ntaus ntawv siv ua ntej (IDP) nyob rau hauv qhov chaw pib kho qhov muag thiab lub limiting post-amplifier IC. Cov kev sib hloov cov neeg siv cov standardx LC connectors rau fiber ntau txuas thiab muab kev ncua ntev txog li 80 km. Tsis tas li ntawd, cov kev sib tham tau zoo raws li SFP Cov Ntawv Pom Zoo Txaus (MSA) Specification thiab SFF-8472.
● Cov Ntaub Ntawv Ceev:
► Cov ntaub ntawv txog 1.25 Gbps;
► Tshem tawm ntawm SFP qhov chaw ntsaws ntsej muag;
► GSB-1243L-L4CD: 1550 Nm DFB Transmitter thiab 1650 nm PIN Txais;
► GSB-1234L-L4CD: 1310 nm FP Transmitter thiab 1490 nm PIN Txais;
► Txuas kev khiav mus txog 80 km;
► Simplex LC connector;
► Tsawg zog lem;
► Digital diagnostic monitor interface yog ua raws nrog SFF-8472;
► Ua raws li kev soj ntsuam SFP MSA;
► Ua raws li IEEE 802.3z Gigabit Txheem;
► Ua raws li RoHS.
● Daim Ntawv Thov:
► WDM Gigabit Ethernet Links;
► Fiber Channel Links;
► SONET / SDH Cov Khoom Siv Interconnect.
● Nqe lus piav qhia:
| Cov Npaum Siab Tshaj Ntawv | 1.25 Gbps |
Compatibility | Cisco Compatible |
Nrug | 80km |
Cov Ntaus Ntawv Tau Tshaj Tawm | 1000Mbps |
Wavelength | 1550nm-TX / 1490nm-RX |
Muab Tam Sim No | 300 mA |
Interface | LC Duplex |
Fais fab mov | 3.3 V |
DOM Kev Pabcuam | Muaj |
Cable Hom | SMF |
TX fais fab | -9.5 ~ - 3dBm |
Txais Kev Mob Siab | <> |
HS Code | Optical fiber cables-85447000.00 |
● Cov yam ntxwv ntawm tus cwj pwm zoo:
| Cov lus qhia | Cim | Min | Hom | Max | Chav tsev |
40km | |||||
Center Wavelength BXD | λC | 1320 | 1330 | 1340 | nm |
Center Wavelength BXU | λC | 1260 | 1270 | 1280 | nm |
Spectral dav (RMS) | σ | 1 | nm | ||
Nruab Nrab Sab Zog | P0ut | -3 | +2 | dBm | |
Ntxiv Kev Tshaj Tawm | Nc | 3.5 | 6 | dB | |
● Mechanical Specifications:
● Txais qhov muag pom kev:
| Cov lus qhia | Cim | Min | Hom | Max | Chav tsev |
20km | |||||
Center Wavelength BXD | λC | 1260 | 1270 | 1280 | nm |
Center Wavelength BXU | λC | 1320 | 1330 | 1340 | nm |
Reveiver Sensitivity | Koj | -14.5 | dBm | ||
Cov tswv yim siab tshaj | Pmax | 0 | dBm | ||
LOS De Assert | LOSS | -14 | dBm | ||
LOS POM ZOO | LOSA | -25 | dBm | ||
Tsis muaj Hysteresis | LOSH | 0.5 | 4 | dBm | |
40km | |||||
Center Wavelength BXD | λC | 1260 | 1270 | 1280 | nm |
Center Wavelength BXU | λC | 1320 | 1330 | 1340 | nm |
Reveiver Sensitivity | Koj | -16 | dBm | ||
Cov tswv yim siab tshaj | Pmax | 0 | dBm | ||
LOS De Assert | LOSS | -17 | dBm | ||
LOS POM ZOO | LOSA | -27 | dBm | ||
Tsis muaj Hysteresis | LOSH | 0.5 | 4 | dBm | |
60km | |||||
Center Wavelength BXD | λC | 1260 | 1270 | 1280 | nm |
Center Wavelength BXU | λC | 1320 | 1330 | 1340 | nm |
Reveiver Sensitivity | Koj | -22 | dBm | ||
Cov tswv yim siab tshaj | Pmax | -7 | dBm | ||
LOS De Assert | LOSS | -23 | dBm | ||
LOS POM ZOO | LOSA | -33 | dBm | ||
Tsis muaj Hysteresis | LOSH | 0.5 | 4 | dBm | |
80km | |||||
Center Wavelength BXD | λC | 1480 | 1490 | 1500 | nm |
Center Wavelength BXU | λC | 1530 | 1570 | 1580 | nm |
Reveiver Sensitivity | Koj | -22 | -7 | dBm | |
Cov tswv yim siab tshaj | Pmax | -7 | dBm | ||
LOS De Assert | LOSS | -24 | dBm | ||
LOS POM ZOO | LOSA | -34 | dBm | ||
Tsis muaj Hysteresis | LOSH | 0.5 | dBm | ||
Dispersion nplua | 3.0 | dBm | |||
● Cov khoom hluav taws xob:
| Cov lus qhia | Cim | Min | Hom | Max | Chav tsev | Cov lus qhia |
Muab Voltage | Vcc | 3.14 | 3.3 | 3.46 | V | |
Khoom Tam Sim No 20km | Icc | 270 | 350 | mA | ||
Khoom Tam Sim No 40km | 300 | 450 | mA | |||
Khoom Tam Sim No 60km | 300 | 450 | mA | |||
Khoom Tam Sim No 80km | 500 | mA | ||||
Muab Voltage | Vcc | 3.14 | 3.3 | 3.46 | V | |
Muab Tam Sim No | Icc | 300 | mA | |||
Siv Cov Lus Qhia Txawv | Zd | 100 | mA | |||
Input AC Hom Tawm Tswv Yim | 0 | 25 | mA | |||
Txawv Ntawm Tswv Yim Cov Peev Xwm Vias | VID | 150 | 900 | mA | ||
Tag nrho Jitter | ||||||
Cov Ntaub Ntawv Txaus Siab Tshaj | ||||||
Uncorrelated Jitter | ||||||
Qhov muag pob ntseg | Saib SFP + MSA | X1 | UI | |||
Qhov muag pob ntseg | Saib SFP + MSA | X 2 | 0.35 | UI | ||
● Hais Txog Khoom:
Txhua tus neeg hauv transceiver yog ib tus zuj zus mus kuaj ntawm ntau yam khoom ntawm Cisco khoom thiab dhau los ntawm kev soj ntsuam ntawm FOCC qhov kev tswj qhov ntse nruab.
● OEM & Kev Khom Khoom:
Kev koom tes nrog ntau lub chav lag luam OEM cov tub lag luam rau ntau tshaj 8 xyoo, FOCC tau muab cov kev pabcuam siab zoo thiab kev siv nyiaj rau txhua qhov xav tau thiab cov kev ua haujlwm, nrog rau kev tsim kho, tsim khoom tsim, Printed Circuit Board (PCB) layout thiab hluav taws xob tsim, software & firmware tsim, kev sib dhos, cov ntawv sau, thiab lwm yam. Nrog kev muag khoom thiab cov neeg tuaj tawm tswv yim, FOCC tau nthuav dav zuj zus thoob plaws lub ntiaj teb thiab ua qhov chaw pabcuam kev sib txuas lus ntawm kev sib txuas lus.
